Grade A Fireproof HPL Board
Class A fireproof rating with ultra-low deformation rate
Quick Specifications
Product Overview
Grade A Fireproof HPL Board represents the highest standard in fire-resistant decorative panels, manufactured using specialized non-combustible core materials and fire-retardant resin systems. The production process involves impregnating multiple layers of specially treated kraft paper with modified phenolic resin containing fire-retardant additives, then laminating under high pressure (120-150 kg/cm²) and temperature (160-180°C). The result is a dense, homogeneous panel with exceptional fire resistance (Class A per GB 8624-2012), achieving flame spread index ≤25 and smoke development ≤450. With ultra-low thermal deformation rate (<0.2% at 200°C), this product maintains structural integrity during fire events. The high-density core (≥1.45 g/cm³) provides excellent impact resistance and dimensional stability. Available in thicknesses from 6mm to 20mm, suitable for high-rise building interiors, public transportation facilities, commercial complexes, and any application requiring strict fire safety compliance. Meets international standards including NFPA 286, EN 13501-1 (Class B-s1,d0), ASTM E84, and Chinese GB 8624-2012 Class A1. Zero halogen formulation ensures low toxicity and minimal smoke generation during combustion.
Technical Specifications
Physical Properties
| Thickness Range | 6mm - 20mm |
| Standard Sizes | 1220×2440mm, 1300×3050mm, 1530×3660mm |
| Density | ≥1.45 g/cm³ |
| Flexural Strength | ≥100 MPa |
| Impact Resistance | ≥25 kJ/m² |
| Surface Hardness | ≥7H (pencil hardness) |
| Water Absorption | <0.1% (24h) |
Fire Performance
| Fire Classification (China) | Class A1 (GB 8624-2012) |
| Fire Classification (EU) | Class B-s1,d0 (EN 13501-1) |
| Flame Spread Index | ≤25 (ASTM E84) |
| Smoke Density Rating | ≤450 (ASTM E84) |
| Thermal Deformation | <0.2% at 200°C |
| Ignition Temperature | >450°C |
| Oxygen Index | >38% |
Chemical & Environmental
| Halogen Content | Zero (halogen-free) |
| Formaldehyde Emission | E0 grade (<0.5 mg/L) |
| VOC Emission | Low (GREENGUARD certified) |
| Moisture Resistance | Excellent |
| UV Resistance | Good (indoor applications) |
Standards & Certifications
| GB 8624-2012 | ✓ Class A1 Certified |
| NFPA 286 | ✓ Passed |
| ASTM E84 | ✓ Class A Certified |
| EN 13501-1 | ✓ Class B-s1,d0 |
| ISO 9001 | ✓ Quality Certified |
Key Benefits
Grade A Fireproof
Class A1 non-combustible, highest fire safety rating
Ultra-Low Deformation
<0.2% thermal deformation at 200°C
Zero Halogen
Non-toxic smoke, safe for occupied spaces
High Density Core
≥1.45 g/cm³ for superior strength
Impact Resistant
Withstands heavy use in public spaces
Low Smoke Emission
Smoke density ≤450, clear evacuation routes
Dimensional Stability
Maintains flatness under temperature variations
Long Service Life
25+ years in commercial applications
Real-World Case Studies
Proven Excellence in Global Projects
Dubai 2020 Expo
SUN PLUS HPL materials were used for outdoor cabinets and toilet partitions at the Dubai 2020 Expo, demonstrating excellent durability and weather resistance in high-traffic public spaces.
Abu Dhabi Capital Airport
Premium HPL partition systems were installed in Abu Dhabi Capital Airport's facilities, providing hygienic, durable, and easy-to-maintain surfaces for high-traffic airport environments.
Dubai Police Headquarters
SUN PLUS wall panels were selected for Dubai Police Headquarters, offering superior durability, fire safety, and professional aesthetics for government facilities.
Sharjah Police Headquarters
High-performance HPL partitions and cabinets were installed at Sharjah Police Headquarters, combining functionality with professional design for law enforcement facilities.
Dubai Jebel Ali Port Camp
Weather-resistant HPL wall panels were used at Dubai Jebel Ali Port Camp, providing excellent protection against harsh maritime and outdoor conditions.
Russia World Cup Final Venue
SUN PLUS HPL materials were selected for the Russia World Cup final venue, meeting international standards for both indoor and outdoor applications with superior performance.
Expo 2017 Kazakhstan
Premium HPL wall panels were featured at Expo 2017 in Kazakhstan, showcasing the versatility and aesthetic appeal of SUN PLUS materials for international exhibitions.
Canadian International School Dubai
SUN PLUS wall panels were installed at Canadian International School Dubai, providing durable, safe, and aesthetically pleasing surfaces for educational environments.
Dubai University City Laboratory
Chemical-resistant HPL boards and partitions were used in Dubai University City's laboratory facilities, ensuring safety and durability in demanding scientific research environments.
Lebanese University
HPL wall panels were installed at Lebanese University, combining durability with elegant design for academic facilities serving diverse educational purposes.
Riyadh Women's University
Premium HPL wall panels and worktops were selected for Riyadh Women's University, providing functional and aesthetically sophisticated surfaces for modern educational facilities.
Nicaragua Monte Hospital
Durable and hygienic HPL wall panels were installed at Nicaragua Monte Hospital, meeting healthcare facility standards for cleanliness, durability, and professional appearance.
