Compact Board (Antibacterial)
High-pressure laminate with antibacterial properties for public spaces
Quick Specifications
Product Overview
Antibacterial Fireproof Compact Board is manufactured using advanced high-pressure lamination technology with multiple layers of kraft paper impregnated with thermosetting phenolic resin. The production process involves compression at 150°C and 100 kg/cm² pressure, creating a homogeneous, self-supporting panel with exceptional mechanical strength. The surface incorporates silver-ion antibacterial agents that achieve 99.9% bacteria reduction (tested against E. coli and S. aureus per ISO 22196). With a density of ≥1.45 g/cm³, this product offers superior impact resistance (>20N), water resistance (24-hour water absorption <6%), and dimensional stability. The core structure provides excellent sound insulation and thermal properties. Available in thicknesses from 2mm to 25mm, suitable for toilet partitions, locker systems, laboratory furniture, and high-traffic public facilities. Meets international standards including EN 438, NFPA 286, AS/NZS 4586, and GB/T 17657-2013. Fire rating: Class B1 (GB 8624-2012).
Technical Specifications
Physical Properties
| Thickness Range | 2mm - 25mm |
| Density | ≥1.35 g/cm³ |
| Impact Resistance | >20 N |
Key Benefits
Antibacterial
99.9% bacteria reduction, ISO 22196 certified
Impact Resistant
High-density core, withstands heavy impacts
Waterproof
100% moisture resistant, zero water absorption
Fireproof
Class B fire rating, low smoke emission
Self-Supporting
No substrate required, structural strength
Chemical Resistant
Resists cleaning agents and disinfectants
Scratch Resistant
Durable surface for high-traffic areas
Easy to Clean
Non-porous, simple maintenance
Applications
Public Restroom Systems
Heavy UseExtensively used for toilet cubicles, urinal partitions, and vanity countertops in airports, shopping malls, office buildings, and stadiums. The 100% waterproof core and antibacterial surface make it ideal for wet environments with high hygiene requirements. Resists moisture penetration, prevents mold growth, and maintains structural integrity even with constant water exposure. Easy to clean with standard disinfectants. Typical installations include partition panels (12mm thickness), doors (12-18mm), and countertops (12-25mm). Supports various hardware systems and offers excellent dimensional stability.
Sports & Recreation Facilities
Heavy UsePerfect for locker rooms, changing areas, shower partitions, and benches in gyms, swimming pools, and sports complexes. Impact-resistant surface withstands heavy daily use from athletes and equipment. The antibacterial properties help maintain hygienic conditions in high-moisture environments. Resistant to chlorine and common cleaning chemicals. Available in various colors to match facility branding. Typical applications include locker doors, bench seating, wall cladding, and floor-to-ceiling partitions.
Healthcare Facilities
Heavy UseWidely adopted in hospital patient rooms, nurse stations, examination rooms, and medical equipment storage areas. The antibacterial surface (99.9% efficacy) helps prevent healthcare-associated infections (HAIs). Easy to sanitize and resistant to medical-grade disinfectants. Non-porous surface prevents bacterial colonization. Used for privacy screens, bedside cabinets, wall protection panels, and mobile medical carts. Meets healthcare facility infection control standards.
Educational Institutions
Heavy UseIdeal for school and university restrooms, laboratory furniture, cafeteria partitions, and corridor wall panels. Durable enough to withstand student traffic while maintaining appearance over 15-20 years. Graffiti-resistant surface can be cleaned easily. Cost-effective solution for educational facilities with limited maintenance budgets. Common installations include toilet partitions, lab benches, cafeteria tables, and locker systems.
Transportation Hubs
Heavy UseEssential for airports, train stations, bus terminals, and metro stations where high passenger volume demands durable, low-maintenance solutions. Resists impact from luggage and equipment. The antibacterial properties address public health concerns in high-traffic areas. Used for restroom partitions, information kiosks, seating systems, and wall cladding. Withstands 24/7 operation with minimal maintenance requirements.
